Bilstein Shock Absorbers

Bilstein AS2 Series (BV) shock absorbers feature an aluminum threaded body construction with racer-rebuildable design. The 46mm internal bore monotube design also incorporates a base valve assembly that allows for lower gas pressures that can provide additional grip. The threaded body design increases heat dissipation as well as providing precise ride height adjustments when using as a coilover. The hard anodized coating reduces internal friction and improves strength and durability (pistons and piston bands are sold separately to allow for a variety of combinations). AS2 Series (BV) shock absorbers are ideal for racers looking for an aluminum rebuildable design with expanded tuning options for superior performance.

• Bilstein AS2 (BV) Series shock absorbers feature an aluminum threaded body design with base valve technology to deliver superior grip with lower nitrogen pressures.
• These 46mm dampers are designed with single adjustable shafts for additional tuning capabilities and can be used with our without coilover hardware
• The AS2 (BV) Series offers increased grip and traction in a rebuildable design with multiple tuning options.

Vehicle Specific

• No Applications

Attributes:

• Brand Name: Bilstein
• GTIN: 00651860963815
• Adjustable Damping: Single Adjustable - Rebound
• Body Design: Threaded Body Screw Top (Coilover)
• Body Material: Aluminum
• Boot Included: No
• Collapsed Length (IN): 13.91
• Collapsed Length (MM): 353.2
• Extended Length (IN): 20.49
• Extended Length (MM): 520.5
• Finish: Clear Anodized
• Internal Design: Monotube
• Lower Mount Type: 1/2in teflon heim
• PartType: Shocks / Struts
• Piston Diameter: 46mm
• Piston Type: Sold Separately
• Segment: Motorsports
• Series: AS2 Series (BV)
• Shaft Diameter: 14mm
• Spring Seat Included: No
• Stroke/Travel Length (IN): 6.59
• Stroke/Travel Length (mm): 167.4
• Upper Mount Type: 1/2in teflon heim

Extended Information:

• Country of Origin: United States
• Emissions : 4
• Life Cycle Status: Available To Order

Packing Information:

• Quantity of Each: 1.0
• Package UOM: EA
• Dimension: 22.4500 x 2.9500 x 2.9500 inches
• Weight: 7.0000 POUNDS
