Carbon Scout Pro - 20000lb Extreme Duty Truck Winch 24V

The Scout Pro 20K is built for serious recovery on heavy-duty 24V rigs. With 20,000lb of pulling capacity, a 7HP series-wound motor, and a rugged build, it’s made for oversized trailers, expedition trucks, and heavy work vehicles. Whether hauling, rescuing fully loaded 4WDs, or tackling brutal off-road conditions, this winch delivers dependable, uncompromising power.

• 20,000lb (9,072kg) Rated Pull – Maximum capacity for extreme recoveries
• 7HP Series-Wound Motor – Delivers high torque for confident pulling
• 345:1 Gear Ratio – Optimized for controlled, powerful winching
• 82ft (25m) Synthetic Rope – Strong, lightweight, and easy to handle
• Mounting Bolt Pattern – 10in x 4.5in (254mm x 114.3mm)
• Drum Dimensions – 3.46in x 8.82in (88mm x 224mm)
• Winch Dimensions – 22.8in x 7.6in x 8.8in (579mm x 192mm x 224mm)
• IP68 Rated – Fully sealed against dust and water
• Wired + Wireless Remotes – Flexible operation options
• Rotating Ring Gear Clutch – Quick shift between freespool and engaged modes
• Automatic Load-Holding Brake – Prevents rollback and overheating
